paper cup machine making disposable paper cups

paper cup machine making disposable paper cups

    Unit Price: 20000~22000 USD
    Min. Order: 1 Set/Sets
    Packaging: The machine making disposable paper cups will be packaged with export standard wooden case
    Supply Ability: 30 Set/Sets per Month
    Port: Ningbo/Shanghai

Product Description


Product Description



machine making Disposable Paper Cups

The speed of this model high speed Paper Cup machine is 70-80/min and sealing system is adopted ultrasonic sealing.

 High quality paper cup machine making disposable paper cups

MACHINE DESCRIPTION

High- speed paper cup machine is our latest machine, which is made by us base on our 20 years manufacturing experience and advanced technology from oversea countries, it is a pioneer equipment in china. Thanks to the sealing station is adopted ultrasonic sealing, so this model machine can produces various Cups for hot and cold beverages; Ice cream, yoghurts, soups and snacks using single side or double sides PE coated paper. As one of our most popular models, it has its own compact structure, the machine runs steadily and fastly, finished cup with good quality, lowest waste percentage and less noisy, it is the best choice for making any type Paper Cups.



CHARACTERISTICS

1)The material of cup mould is adopted aluminum instead of carbon steel,owing to the aluminum material is light than carbon steel so it assure the machine running faster than the general paper cup machine.

2)The 90degree revolve transfer cup. It make the forming cup 100% to transfer to mould, reduce the rate of wasting.

3)The cup bottom can be transferred by one time. It mean the cup bottom can be transfer to cup inside, with highly exactness, reduce the wasting when transfer the second time.

4)Revolve curling bottom. It reduce the touch about cup bottom printing and make the bottom curling equality. It will not destroy the printing surface and the two sides PE paper bottom surface.

5)The parts of machine with nice craftwork. It make sure every part can exchange by each other.

6)Tks to the bolwing air system,the finished paper cups are blowing to certain place to stacking THROUGH a piece of windpipe.



MAIN TECHNICAL PARAMETER

Model

HSZB-1 model high-speed paper cup machine

HSZB-2 model high-speed paper cup machine

Production capacity

70-80PCS/min

70-80PCS/min

Required paper

150-400gsm Single Side PE Paper or Double Sides PE Paper

200-400gsm Single Side PE Paper or Double Sides PE Paper

Cups Range

(A)Top Dia: 60 -125MM ,(B)Height:60-190MM (C)Bottom Dia: 50 -97MM , (D)Knurling:5 -11 MM

(A) Top Dia:90 -160MM ,(B)Height:60 -190MM (C)Bottom Dia: 80 -130MM , (D)Knurling:6 -11 MM

Total power

380V 50HZ 12KW

380V 50HZ 12KW

Air supply requirement

Working pressure: 0.5-0.7working gas volume: 0.8m3 /per minute

Working pressure: 0.5-0.7working gas volume: 0.8m3 /per minute

Weight

2300 kg

2600kg

Overall dimensions (L*W*H)

3200*1700* 2000mm

3200*1700* 2000mm






Packaging & Shipping



 High quality paper cup machine making disposable paper cups

High quality paper cup machine making disposable paper cupsHigh quality paper cup machine making disposable paper cups







Our Services



Why Choose Us?



We are confident in the following to ensure you should choose us!



Professional:We are professional manufacturer of Paper cup making machines. Professional, very well experiences can ensure our machine is quality controlled and reliable.



Quality Control:We have been engaged in paper cup making machinery and mold processing and plastic processing for many years and also have many experienced technical staff members. So we can guarantee our productsquality is the best.



Reasonable and competitive price:Not only the machine we provided is quality controlled, but also we provide very reasonable and competitive price to you.



Excellent Service: We offer Installation Services, Clients Training Services and Preventative Maintenance and After Sales Service (we offer one year guarantee period). So you can feel relieved after buying our products. Once you bought our machine, we will prepare some related easy-broken spare parts together with the machine for one year. During the machine running, if you met any troubles, we will reply to you within 24 hours, and get the solution within 48 hours upon getting your feedback.



Product Development:We develop new ideas all the time. So these enables our customers to share a great selling point when compete with their own competitors. This keeps us leading the market.



Experienced Sales Team: Our sales team is experienced, and they all know our product well. So we can give you the best service all the time.
